Description
TGI D380N Green Up Dryer
TGI D380N Green Up Dryer features
Industrial Construction Dryer, Fixed Model, capacity up to 164 Kg.
Stainless steel steam batteries.
Stainless steel drum.
Automatic final cool down.
Choice of Steam and Gas Heated models.
Error detection system.
Reversing drum.
Freely programmable microprocessor.
TGI D380N Green Up Dryer
Technical Data
| Steam |
 |
|
| |
| Dimensions | units | Model | |||
|---|---|---|---|---|---|
| D290 Green Up | D380 Green Up | D470 Green Up | |||
| Drum: Ø | mm | 1750 | 1750 | 1750 | |
| Drum: depth | mm | 1650 | 2050 | 2450 | |
| Drum: volume | dm3 | 3970 | 4930 | 5890 | |
| Loading capacity (1:30) | Kg | 132 | 164 | 196 | |
| Compressed air pressure | Bar | 6 – 7 | 6 – 7 | 6 – 7 | |
| Electric Consumption | KW | 12 | 16 | 21 | |
| Steam | Recommended steam pressure | Bar | 10 | 10 | 10 |
| Maximum steam consumption | Kg/h | 350 – 400 | 450 – 500 | 550 – 600 | |
| Average steam consumption per cycle* | Kg | 136 | 180 | 220 | |
| * In correct use conditions | |||||
Available Accessories
Optional Accessories
A wide range of additional equipment continuously updated.
More control possibilities, use better efficiency, many different processes, more automation and a multitude of combinations available to make your own industrial laundry.
|
|
|
|
|
|
|---|---|---|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
